Module Type:Dual Analog Input
Compatibility:Compatible with GE Fanuc PACSystems RX3i PCI Bus
Input Channels:2 Channels
Input Types:Voltage and Current
Filter Frequency:Six hardware configurable filter frequencies per channel
Auto Calibration:Automatic calibration at each filter frequency
Alarm Detection:High, high-high, low, low-low alarm detection
Diagnostic Support:Supports diagnostic points in logic program for fault detection
Temperature Display:Temperature display in Celsius or Fahrenheit
Configuration:Fully software configurable without jumper settings
Status Indicators:Flash memory module status, field status, and terminal block LEDs
This high-performance dual analog input module is designed for industrial applications where precision and reliability are paramount. With two independent analog input channels capable of handling signals ranging from ±10V to ±5V, it offers a wide range of measurement capabilities suitable for a variety of sensor types including thermocouples, RTDs, and strain gauges.
The module features a 16-bit resolution, ensuring accurate data capture even in demanding environments. It supports sampling rates up to 1000 samples per second, making it ideal for real-time monitoring and control applications.
Designed for ease of use, the 2AI-I2V module can be configured through software without the need for physical jumpers or settings. Each channel is independently configurable for filter frequency and input type, offering maximum flexibility.
Robust design ensures the module operates reliably across a wide temperature range (-40°C to +85°C), making it suitable for harsh industrial conditions. Power supply requirements are minimal, operating within a range of 10-30V DC, which simplifies integration into existing systems.
With support for RS-485 and Modbus RTU communication protocols, the module easily integrates into existing control systems. Its compact size and DIN rail mounting make installation straightforward and space-saving.
