Control Power nominal:50-300 VDC / 40-265 VAC
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
Communications:non-isolated RS232 port, RS485 port
Differential Switch Time Delay:<200 ms
Event Record Triggers:power fail, alarms, self test, inhibit, trip, waveform capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE Multilin 369-HI-0-M-0-0-0 is a high-performance motor management relay designed to protect and manage motors in industrial settings.
This model is equipped with an optional metering package that allows for real-time monitoring of critical parameters, helping to optimize performance and reduce maintenance costs.
With waveform capture and event reporting capabilities, users can quickly diagnose issues and minimize downtime.
The relay features true RMS phase current input conversion, ensuring accurate measurements even under varying load conditions.
Designed for reliability and ease of use, the 369-HI-0-M-0-0-0 is compatible with a wide range of voltages and frequencies, making it suitable for diverse applications.
Its robust design and reliable performance make it an ideal choice for industrial control systems where precise motor management is crucial.
