Model Type:Digital DC Output Module
Model Number:1746-OG16
Manufacturer:Allen Bradley
Number of Channels:16
Input Voltage:24 VDC
Output Voltage Range:10 – 50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 MA
Load:1 MA
Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A At 60 DEG C, Continuous Current Per Module: 4 A At 60 DEG C
Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Processor:SLC 500
Enclosure Type:Open Type
Mounting Method:Chassis
Temperature Rating:0 – 60 DEG C
Environmental Conditions:5 – 95% Relative Humidity (Non-condensing)
The Allen-Bradley 1746-OG16 is engineered to deliver exceptional performance in a variety of industrial control scenarios. With its high-resolution and accuracy, it ensures precise analog signal generation, crucial for applications requiring fine-tuned control over actuators or sensors.
Featuring an IP20 enclosure, this module is robust enough to withstand harsh industrial environments, ensuring reliable operation in challenging conditions. It supports a wide voltage range of 10-30VDC, providing flexibility across different systems and applications.
The 1746-OG16 is compatible with Modbus communication protocol, facilitating seamless integration with a wide array of Allen-Bradley and third-party control systems. This makes it an ideal choice for modern, interconnected factory setups.
With 16 outputs, the module offers versatile configuration options, allowing users to customize their control solutions according to specific needs. Whether controlling motors, heaters, or other devices requiring analog signals, this module excels in delivering consistent, high-quality performance.
Engineered with attention to detail, the Allen-Bradley 1746-OG16 is not just a component; it’s a tool that empowers engineers and technicians to build more efficient, responsive, and reliable control systems. Its compatibility with Allen-Bradley’s comprehensive ecosystem ensures a streamlined setup process and long-term support.
