ABB DC522 1SAP240600R0001 – Advanced Digital Input/Output Module for Efficient Control Solutions

Type:Digital I/O Module

Manufacturer:ABB

Model:DC522 1SAP240600R0001

Compatible with:S500 PLC

Power Supply:DC Voltage

Operating Range:0-24V DC

Current Load:50mA per channel

Signal Level:TTL/CMOS

Number of Channels:8 Input, 8 Output

Communication Interface:RS-485

Dimensions (WxHxD):112mm x 74mm x 51mm

Weight:0.2kg

    The ABB DC522 1SAP240600R0001 module is designed for industrial automation environments, ensuring stable performance in harsh conditions. Its compact size facilitates easy integration into existing systems without compromising functionality.

    With a wide operating voltage range, this module supports diverse applications across various industries. The modular design allows for flexible installation, making it an ideal choice for space-constrained areas.

    Featuring 16 digital inputs and outputs, it enables precise control over machinery and processes. The MODBUS RTU interface simplifies communication between the module and other system components, enhancing overall system efficiency.

    Engineered for durability, the module withstands extreme temperatures from -25°C to +60°C, ensuring reliable operation in diverse environments. It also offers protection against humidity up to 95% RH, making it suitable for manufacturing floors with varying environmental conditions.

    The IP20 enclosure rating provides basic protection against accidental contact and dust ingress, safeguarding the internal components from damage. The terminal block connection ensures secure wiring, minimizing downtime due to loose connections.
