Product Type:Analog Input Module
Manufacturer:Allen-Bradley
Model Number:1746-NL8
Channels:4
Common Mode Voltage Range:-20 To 20 V
Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS
Input Range:-20 To 20 MA
Absolute Input Current:-30 To 30 MA (Max)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Input Range (DC):-10 To 10 VDC – 1 LSB
Current Rating:Backplane Current Draw: 35 MA at 5 V, 85 MA at 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The Allen-Bradley 1746-NL8 Analog Input Module is specifically designed for high-precision data acquisition in industrial settings, ensuring reliable performance across a wide range of applications.
Equipped with advanced signal processing capabilities, this module offers unparalleled accuracy and stability, even under extreme environmental conditions.
Featuring an IP20 enclosure for dust and splash resistance, the 1746-NL8 ensures robust protection against potential hazards in industrial environments.
With its versatile 24-pin terminal block connection, this module facilitates easy integration into various control systems, simplifying installation and maintenance processes.
Offering a broad input voltage range of -10 to +10 VDC and an accuracy of ±0.05% of full scale, the 1746-NL8 guarantees precise measurement results, critical for achieving optimal operational efficiency.
